Product Description
Features
Space-saving design
Allows you to create a full refrigerator-freezer with independent controls in a slim-fitting footprint
8 cu.ft. automatic defrost all-refrigerator with digital controls, wire shelving, and keyed lock for added security
Compact manual defrost all-freezer with digital thermostat and wire shelving
Powder-coated handle with naturally occurring silver ions to help reduce germ spread
Unit ships in three boxes for customer to install the StackRack on the bottom refrigerator/freezer and place and secure the other unit on top
Designed and purpose-built for pharmacy, medication, and vaccine applications to support meeting CDC/VFC guidelines
The published temperature variation is derived from the maximum deviation of an NTC sensor in a 1 oz. vial located nearest the chamber geometric center during a 24 hour test period
Intuitive controls let you adjust the interior temperature between 2 to 8ºC (refrigerator) and -20º to -15ºC (freezer)
Visual and audible alarms alert if the interior temperature rises or falls out of set range
Electronic controller is equipped with a volt-free contact for alarm forwarding to an external remote system (contacts located in the external rear of the unit)
Adjustable cycle defrost operation ensures the unit avoid temperature spikes and ice buildup
Static cooling system for reduced temperature fluctuations
Both units include a pre-installed probe hole to allow easier connection to user-provided monitoring equipment
Alarm will sound if the door is left ajar for over 4 minutes (adjustable from 1-99 minutes)
Battery-powered alarm sounds if the power connection is interrupted
Audible and visual alarm warns if the sensor is disrupted
Control panel requires password entry to adjust the parameters beyond the set point
Digital controls with a large LED readout in Celsius or Fahrenheit for intuitive temperature management
Control panel provides a readout of the low and high temperatures in 15 minute increments
Keyed lock conveniently located towards the top of the door for added security (2 keys included for each unit)
Designed to accommodate a variety of sizes for flexible storage
Energy efficient LED lighting with internal on/off switch
User-reversible door swing for added flexibility
Added protection in busy settings; NOTE: door is not self-closing once reversed to an LHD swing
Secure three-pronged cord for added unit safety
Standard unit ships with a right hand door swing. For a left hand door swing, add option LHD upon order (due to its construction, this door is not reversible in the field)
Quality door gaskets ensure a tight seal for energy savings and improved performance
2 years parts and labor/5 years compressor
Using environmentally friendly hydrocarbons refrigerants for a greener footprint
Ships with removable warning stickers for "DO NOT UNPLUG," "DO NOT ADJUST TEMPERATURE," and "DO NOT STORE PERSONAL ITEMS"
Compatible with Pyxis®, Omnicell®, and AcuDose RX®
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Overview | |
---|---|
Height of Cabinet | 76.5" (194 cm) |
Width | 23.38" (59 cm) |
Width with Door Open | 23.88" (61 cm) |
Depth | 24.38" (62 cm) |
Depth with Handle | 26.13" (66 cm) |
Depth with door at 90° | 46.5" (118 cm) |
Capacity | 9.8 cu.ft. (278 L) |
Defrost Type | Automatic |
Door | White |
Cabinet | White |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Amps | 2.2 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 204.0 lbs. (93 kg) |
Shipping Weight | 240.0 lbs. (109 kg) |
Parts & Labor Warranty | 2 Years |
Compressor Warranty | 5 Years |
UPC | 761101077659 |
Refrigerator-Freezer | |
Door Swing | RHD |
Reversible | Factory Reversible |
Adjustable Shelves | Yes |
Interior Light | Yes |
Refrigerator - Interior Height | 41.25" (105 cm) |
Refrigerator - Interior Width | 20.0" (51 cm) |
Refrigerator - Interior Depth | 17.0" (43 cm) |
Refrigerator - Capacity | 8.0 cu.ft |
Refrigerator - Shelf Type | Wire |
Refrigerator - Shelf Qty | 7 |
Refrigerator - Temperature Range | 2 to 8ºC |
Refrigerator - Refrigerant Type | R600a |
Refrigerator - Refrigerant Amount | 1.73 oz. |
Freezer - Interior Height | 18.5" (47 cm) |
Freezer - Interior Width | 13.5" (34 cm) |
Freezer - Interior Depth | 13.0" (33 cm) |
Freezer - Capacity | 1.8 cu.ft |
Freezer - Shelf Type | Wire |
Freezer - Shelf Qty | 2 |
Thermostat Type | Digital |
Fan Type | Interior |
Freezer - Temperature Range | -20º to -15ºC |
Freezer - Refrigerant Type | R600a |
Freezer - Refrigerant Amount | 0.8 oz. |
